ALL IN ONE LiFePO4 lithium ion batteries solar energy system 3.2v 50Ah 80Ah 100Ah 105Ah 202Ah 230Ah 280Ah 300Ah lifepo4 battery

2022-07-27 11:07

Specification

Battery	With QR Code	Voltage	Capacity	Max Charge Current	Max Dis. Current	AC IR.	Weight	Dimension (mm)
LF50K	Yes	3.2V	50Ah	100A	150A	≤0.5mΩ	1.5kg	H185W135T30
LF80	Yes	3.2V	80Ah	80A	240A	≤0.5mΩ	1.7KG	H170W130T36.7
LF100	Yes	3.2V	100Ah	50A	300A	≤0.5mΩ	2kg	H118.5W160T50
LF105	Yes	3.2V	105AH	105A	315A	≤0.15mΩ	2kg	H196W13037
LF120	Yes	3.2V	120Ah	240A	120A	≤0.5mΩ	2.84kg	H166W174T48
LF160	Yes	3.2V	160AH	320A	320A	≤0.5mΩ	3.0KG	H157W174T54
LF202	Yes	3.2V	202AH	100A	200A	≤0.25mΩ	4.06kg	H173T54H209.6
LF230	Yes	3.2V	230AH	230A	230A	≤0.25mΩ	4.2kg	H200W173T72
LF280	Yes	3.2V	280AH	280A	280A	≤0.25mΩ	5.3kg	H208W173T72
LF304	Yes	3.2V	304Ah	300A	300A	≤0.25mΩ	5.5KG	H200W173T72
LF302	Yes	3.2V	302Ah	300A	300A	≤0.25mΩ	5.4KG	H206W175T73

Grade A and Brand New

5 Year Warranty

High energy density

Long cycle life

Wide application

High discharge rate

Safety: Excellent abuse tolerance and environmentally friendly

Life: Excellent calendar and cycle life.

Applications

Passenger and commercial plug-in hybrid electric vehicles (PHEVs)

Passenger and commercial battery electric vehicles (BEVs)

Solar power storage ,e-bike , e scooter, golf cart And Others .

Wildly use battery, model aircraft, electric tools,power tools , Golf carts, sightseeing coaches,diy battery pack ,solar energy, inverters and others

Our Factory

Packing And Shipping

* Use high hardness custom sponge to strengthen the battery* 5 layers of dangerous goods export corrugated carton
* Positive and negative paste insulation tape
* We will label test data on each cell before delivery
* If customer have requirement, we can provide Wooden Packing for shipping.

About the shipping
1	USA	ETD:3-7 days	The tracking will be update after pick up by local express.Usually it will take around 15-25 days after delivery.	By sea+FEDEX Delivery(DDP,Tax free)
		ETA:25-30 days after delivery
2	EU	ETD:3-7days	The tracking will be update after pick up by local express.Usually it will take around 20-30 days after delivery.	By railway+UPS(DDP,Tax free)
		ETA:30-35 days after delivery
3	AU	ETD:3-7 days	The tracking will be update after pick up by local express.Usually it will take around 15-25 days after delivery.	By sea+Delivery(DAP)
		ETA:25-30 days after delivery
4	We can't deliver the following address directly
A	USA: Military address and PO box address are not acceptable; Puerto Rico, Virgin Islands, Guam, Alaska Note: Hawaii does not include customs duties and requires additional freight, Please contact us online.
B	Portugal: Azores and Madeira
C	Spain：Canary Islands, hueda and melilia
D	Russia: Kamchatka Peninsula
E	Other:Some remote areas not listed，Please provide shipping address and zip code to us to check.
Noted: * The tracking will be update after pick up by local express. Please wait patiently or contact us for help. * Countries that do not appear in the table, Please contact us freely for freight charges

FAQ

1). Are the batteries GRADE-A,Brand NEW?
Yes, GRADE A + quality. the QR code is intact, Brand new.

2).Are the batteries come with busbars+bolts?
The price come with Bus bars and Bolts，One Battery will come with one set bus bar and bolt（e.g.,If buy 4pcs battery,we will send 4pcs cells with 4pcs busbars and 8pcs bolts）If need more please contact us online.

3).Can you test each battery PRIOR to shipping?
We will test all the battery Voltage and Internal resistance before shipping.

4.)What kind of the package of the cells?
Pack with strong package, each cell into thickness PE foam or bag, then into 5 layers strong carton.

5).How can I do if I need more help for the order?
You can chat our sales online or send inquiry email,we will respond you ASAP.

Reminder
DIY battery pack must get the cells balanced (same voltage ) before assembly. Later if there happens don't know how to assembled or wrong assembly is not accepted refund. Professionals will detected voltage/resistance/appearance and other issues before every shipment, we can only ensure that the single battery is good, when arrival you can test the cells within 15 days, after that means batteries have no problem, does not provide return nor refund. If you found problems you can contact us for return or refund. Battery can only be unused (the electrode intact, no welding, no wear, the appearance good) to provide return. Any return behavior buyers need to be responsible for shipping fee.

1).Warranty period 5 years(from the date of successful delivery),if the single battery capacity less than 80% initial capacity,take the test pictures or video to us,we will replace it or give satisfied solution.

2).If any miss or damaged for the shipping Please contact us firstly, then send us the picture or video to check. In case of loss of cargo or the battery is damaged and can not be used or there is a greater risk of use, we will communicate with buyer if resend it or replace it or refund the product cost.If buyer send back the cells to seller,buyer should pay for the shipping cost.

3).These situations not provide return nor refund
1. After the assembly or assembly process happen any problem, such as the protection board connected to the wrong wire burned lead to battery damage, charger failure, the assembly error or unbalanced assembly, etc.
2. For damage caused , such as battery bulge/welded, battery pack without protection BMS caused by charging.

Tips
* These products are prototype batteries without protection board, you need to purchase a match one! Pls click here to consult us.

* please consider before taking orders, place order means you have agreed. thank you for your cooperation!

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
