OEM Battery Rechargeable 12V 30Ah 4S5P Lithium 2000+ Deep Cycle Lifepo4 Cell Manufacturer

2021-01-21 07:16

Specification

Electrical Characteristics	Nominal Voltage	12.8V
	Nominal Capacity	[email protected]
	Energy	384Wh
	Internal Resistance	=50MO
	Cycle Life	2000 [email protected] Charging/Discharging until 70% Capacity
	Self Discharge	=3.5% per month at 25℃
Standard Charging	Max Charging Voltage	14.0~14.6V
	Charging Mode	At 0℃~45℃temperature, charged to 14.6V at a constant current of 0.2℃, and then charged continuously with constant voltage of 14.6V until the current was not more than 0.02C
	Charging Current	15A
	Max Charging Current	30A
Standard Discharging	Discharging Current	15A
	Max Continuous Current	30A(<3S)
	Max Pulse Current	100A(<3S)
	Discharging Cut-off Voltage	10.0
Operating Condition	Charge Temperature	0℃to 45℃@ 60+/-25% Relative Humidity
	Discharge Temperature	-20℃ to 45℃ @60+/-25% Relative Humidity
	Storage Temperature	0℃ to 45℃ @60+/-25% Relative Humidity
	Water Resistance	IP55
Structure	Cell&Format	IFP 32700 N60,4S5P
	Casing	Plastic
	Dimension	22395175*175
	Weight	Approx 3.5kg
	Terminal	M6

Features of LiFePO4 battery

Longer Cycle Life: Offers up to 20times longer cycle life and five times longer float /calendar life than lead acid battery.
Lighter Weight: About 40% of the weight of a comparable lead acid battery. A 'drop in' replacement for lead acid batteries.
Higher Power: Delivers twice power of lead acid battery ,even high discharge rate, while maintaining high energy capacity.
Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.
Increased Flexibility: Modular Design enables deployment of up to up to ten battery in parallel.

NOTES

Do not use the 12V lithium battery pack in places with high humidity or where it may be exposed to wet.
Do not modify or disassemble the power bank.
Do not throw the 12V power bank into fire or water.
Do not reverse the polarity of the battery pack.

Related LiFePO4 Battery

Application

1) Energy Storage: UPS , backup ,power station.
2) EV : Golf trolleys , Electric scooters .Electric Bike ,Electric tricyle ,Electric Motor.
3) Solar System,Wind Energy Storage,Solar/Storage Home System, Solar Street Light.
4) Telecommunications Base Stations.
5) General Energy Storage (Such as: Back-up Power, Miner's lamp, portable power supply, digital products etc.)

Our Factory

Packing And Shipping

Packing

Seaworthy Carton to fully protect batteries on the way.
Each battery packed in polyfoam ,then put in 3 layer brown box,some related pcs put in 5-layer strong brown outer carton

Delivery

1.by UPS/DHL/FEDEX( It takes 3-5 days to arrive after all details confirmed)
2.by air cargo( It takes about one week to arrive after all details confirmed)
3.By sea shipment ( It takes about one month to arrive after received the d eposit and confirmed all details.
4.Port:FOB Hongkong or CIF terms.
5.Shipment date within 30days for mass production .
6.Shipment date within 7-10days for testinng samples .

FAQ

1,Q: What's the main product in ALL IN ONE?
A: Rechargeable battery. Li-ion, Lipo battery and NiMH Battery.

2,Q: What is overcharge?
A: After charge, tested the batteries' initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode. Observe changes in battery appearance.

3,Q: What is over discharge?
A: After charge, test the batteries' initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in battery appearance

4,Q: Can I have a sample order?
A: Yes, we accept sample order to test and check quality. Batteries can be made as require.

5,Q: Do you have MOQ limit?
A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.

6,Q: How about the lead time?
A: Samples will takes 5-7 business days. Mass production will takes 15-25 days. It depends on quantity.

7,Q: How about shipping and delivery time?
A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DP service, delivery time is 11-15 business days. Airline and sea shipping also available.

8,Q: What about after-sale service?
A: We will offer you 1 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.

Why choose ALL IN ONE Manufacture?
1.We have our own factory with professional lithium ion battery pack for many years.
2. We have a strong R&D team and carrer business team.
3. Offering OEM service for your order.
4. Reply within 8 hours.
5. Offering competitive price, good after-sales service.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
