Lithium li ion lifepo4 battery 72v 100ah with smart bms

2020-11-11 03:42

Parameter

ModelAIN-72100ah/24S4P
Nominal voltage72V  ( 25.6V)
Charge voltage87.6V
Nominal capacity100ah
Battery size605*395*245mm
Net weight76.0KG, GROSS 90 kg WITH wood pallet package BOX 112.0 kgs
Battery cell typeLithium ion  pouch cell 25ah cell
Lifecycle2000 times
Max continuous charge current50A
Peak  discharge current BMS100A
Max peak discharge current100A /1c,  max peak curent instantly 250A, 2.5C
Charge methodCC/CV
Charge temperature0-65°C
Discharge temperature-40-60°C
BMS protectionover-charge,over-discharge,               over-current,short circuit
CERTIFICATESCE, ROHS

Product feature and characterisitcs :

1) Environmental friendly green lithium power energy battery ,

2) High density of energy

3) Light weight li-polymer lifepo4 flat cell type  25ah /pcs

4) Low self-discharge  3% per 3 months

5) Low internal resistance : 50

6) Long cycle life, cycling 1500-2000 times

7) No memory effect

8) Doesn’t contain Mercury, No fire, No explosion, No leakage

Applications

Lithium Battery Applications

Engine Starting Battery

Commercial Bus and Transit: E-car, E-bus, Golf trolley/car

E-bike, Scooter, RV, AGV, Marine, Tourist car, Caravan

Wheel chair, E-truck, E-sweeper, Floor cleaner, E-walker etc.

Intellectual Robots

Packing and Shipping



FAQ

Q: What are there included for a battery or pack , may i buy charger from you?
A: Battery case, BMS, battery pack,  can buy customzied connector, charger
Q:  How long does it take to recharge the battery?
A:  usually it takes 5-6  hours with 20A standard charger.  Fast charger  50A max  charging full in 2-3 hours.

Q: How long I can get it?

A:If small quantity, delivery date about  15 working  days after payement, shipping delivery depends on the agents flights schedules.

Q:What's the warranty?

A:2 YEARS  warranty from the delivery date. Man-made problems not in warranty.

Q: Can i customize the size of battery?

A: Of course yes if yourquantity MOQ  workable.



Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
