lifepo4 battery 48v 100ah deep cycles

2021-02-03 01:55

Specification

Product name	lifepo4 battery 48v 100ah 200ah lithium polymer battery
Nominal Voltage	48V
Nominal Capacity	100Ah
Standard Charge Current	10A (0.2C rate)
Max. Charge Current	100 A (1C rate)
4Organization way	15S1P 3.2V100AH LiFePO4 cells battery
Working voltage	2.5- 3. 65v
Standard charging current	100ah
Charge Cut-off Voltage	3.65V
Discharge Cut-off Voltage	2.5V
Inner Resistance(Impedance)	≤ 0.3 mΩ (At 0.2C rate, 2.0V cut-off)
Weight	60kg
Battery cell type	LiFepo4 battery for solar panel or solar heating system or electric car battery pack use
Dimension	customized
Operating Temperature	Charging:0°C ~ 55°C, Discharging: -22°C ~ 55 °C
Storage Temperature	Storage Temperature -20°C ~ 60°C
Cycle Life at 0.2C Discharge,100% DOD≥2000 times (100%DOD till 80% of initial capacity at 0.2C rate, IEC Standard)

Advantage

Longer Cycle Life Offers up to 20 times longer cycle life and five times longer float/ calendar life than lead acid battery, helping to minimize replacement cost and reduce total cost of ownership.

Lighter Weight About 40% of the weight of a comparable lead acid battery. A' drop in' replacement for lead acid batteries.

Higher Power Delivers twice power of lead acid battery, even high discharge rate while maintaining high energy capacity.

Wider Temperature Range -20℃~60℃

Superior Safety Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact, overcharging or short circuit situation.

Increased Flexibility Modular design enables deployment of up to four batteries in series and up to then batteries in parallel.

Related LiFePO4 Batteries

Why Choose Us

1. ALL IN ONE has focused on research,manufacture and sales of lithium battery industrial over 7 years

2. OEM. ODM services are available. welcome to contact us anytime!

3. Orginal Factory with most competitive price and fastest delivery time.

4. ALL IN ONE lithium batteries have passed many international testing, such as CE, RoHs, UN38.3, MSDS,CB,PSE,ISO9001 etc

5. Complete quality management system and nice after-sales services

6. ALL IN ONE has cooperated with many big distributors in many countries, such as USA, CA, UK, France, Italy

Our Factory

The batteries are manufactured in our factory and ready for shipment now

Packing And Shipping

FAQ

1,Q: What are the main products manufactured in ALL IN ONE?A: Rechargeable batteries.NiMH, Li-ion and Lipo battery.

2,Q: What is overcharge?

A: After charge, tested the batteries’ initial state and capacity. Charge to 10.0V at 3C current, then charge to 0.01C at CV mode. Observe changes in battery appearance.

3,Q: What is over discharge?

A: After charge, test the batteries’ initial state. When the batteries are normal, discharge to 0V at 0.5C. Observe changes in battery appearance

4,Q: Can I have a sample order?

A: Yes, we accept sample order to test and check quality. Batteries can be made according to your requirement.

5,Q: Do you have MOQ limit?

A: Yes, we have MOQ limit for mass production, but it depends on battery model. Please contact us for details.

6,Q: How about the lead time?

A: Samples will takes 5-7 business days. Mass production will takes 15-25 days. It depends on quantity.

7,Q: How about shipping and delivery time?

A: Generally, battery will be shipped via Express, such as DHL, TNT, FedEx and UPS, delivery time is 3-5 business days. Or DDP service, delivery time is 11-15 business days. Airline and sea shipping also available.

8,Q: What about after-sale service?

A: We will offer you 1 year guarantee. If there are any problems, please inform us, we will offer you positive solutions.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
