25.6V 100Ah Lithium-Ion Lifepo4 Battery Pack Rechargeable Lithium Ion Battery

2022-03-08 03:05

Specification
Basic Parameters
AIN24100
Norminal
Nominal Voltage(V)
25.6
Rated Capacity (Ah)
100
Capacity(Wh)
2560
Physical
Dimension(mm)
525*240*220
Weight(Kg)
29.7
Electrical
Charge Voltage (V)
29.2
Discharge Cut Voltage (V)
20
Constant charge/Discharge
Current(A)
100A/160A/200A
Peak discharge current
200A/320A/400A
Others
Working Temperature (℃)
-20~65
Storage Temperature(℃)
0~45
Cycle Life
4000

Product Advantage

◆ Using the technology of lithium iron phosphate cell, superior safety,thousands of cycles, 100%DOD, under normal conditions.
◆ Built-in automatic protection for over-charge, over discharge, over current and over temperature.
◆ Free of maintenance .
◆ Internal cell balancing.
◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery. ◆ Can be charged using most standard lead-acid charges (set).
◆ Wider temperature range:-20℃~60℃.
◆ Support for Series application expansion (up to 51.2V) and two in parallel.

Application
Our Factory
Packing And Shipping
FAQ

Q1. What is the biggest differene between your battery and other suppliers:

A: Safest with longer lifespan.

Q2. Why your battery is safer than others?

A: We adopt Bolt in structure, it is strongest structure with most advanced technology involved. B. We only focus on LiFePO4 Battery pack, made of certificated battery cell. C. Integrated BMS to monitor tempeature, voltage, current to realize over voltage protection, over current protection, over temperature protection, short circuit protection, Reverse Polarity protection.

Q3. Why does your battery ensure longer lifespan than others?

A: With more than 10 years experiences in LiFePO4 Battery pack, unrivalled technical capacity ensured.

B. Olivine LiFePO4 Structure(Most stable structure)

C. Single cell protection(Unique in China)

Q4. How about your batttery delivery time?

A: 1-25 workdays after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

Q5: How about your warranty?

A: 3 years warranty

Q6.Is this product safe?

A:Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance;price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.

Q7.Is this product safe?
A:Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests, no fire, no explosion at any circumstance.

Note: We are a battery manufacturer. All products do not support retail, we only do B2B business.please contact us for product prices!
