18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager

2020-08-25 06:38

18650 3.6V 2.5Ah Power Battery Lishen Battery for Handheld Massager

• Model number:AIN14/4-2500
• Nominal voltage:14.4V
• Nominal capacity:2500mAh
• Battery cell:18650/3.6V/2.5Ah
• Dimension:160×49.6×30.6（Max）
• Application: medical device, massage equipment

Product Detail

Product number: 36AQ076-02

Cell model：18650/3.6V/2.5Ah

Battery specification: 18650/4S1P/14.4V/2.5Ah

Nominal voltage：14.4V

Nominal capacity：2.5Ah

Charging voltage: 16.8V

Charging current: ≤1A

Discharging current: 2.5A

Instant discharging current: 7.5A

End-off voltage: 10V

Internal resistance: ≤250mΩ

Battery weight: 600g

Product dimension: 160×49.6×30.6（Max）

Charging temperature：0～45℃

Discharging temperature: -40～60 ℃

Storage temperature: -20～20 ℃

Temperature protection：/

Battery case: PC

Lithium ion battery protection: short circuit protection, overcharge protection, over-discharge protection and overcurrent protection.

Application field: medical device, massage equipment



Product features

1. Shock-resistant and waterproof: fill in the shock-resistant structure inside the cold rolling metal plate housing to satisfy the requirements of good security and high reliability.
2. Large current operation: adopt high rate power to make sure work under large current.
3. Reliable connection: apply square sheet, which is efficient, safe and reliable.
4. The battery pack has long cycle life, which conforms to the principle of low carbon, energy conservation and environmental protection.
